Product Specification:
Scanning system: 40K high-speed galvanometer, ±30° scanning
Laser: 3000mW red laser (635nm)
3000mW green laser (532nm)
4000mW blue laser (450nm)
Machine size: 195*370*165(H)mm
Weight: 9.95Kg
Packing size: 510*320*285(H)mm
Gross weight: 12Kg
Features:
1. RGB lasers all use high-stability and long-life semiconductor lasers (Diode Solid-State Laser). The laser diode emits laser light directly (similar to a light-emitting diode) when energized. It is highly efficient and stable, and can operate normally at -30°C~50°C. Work.
2. The machine has a two-layer structure design, which is compact, small in size and light in weight.
1) Upper layer: optical path and electrical layer. Completely dust-proof design, no cleaning and maintenance required; the electrical department is arranged on the upper floor for easy installation and maintenance. All the heat from the heating components is directed into the lower radiator.
2) Lower layer: large radiator and power layer, strong wind convection heat dissipation.
3. RGB laser spot and divergence angle: divergence angle: <1.5mrad, spot diameter at the exit <5mm.
4. The laser uses analog modulation technology to linearly control the laser brightness and produce bright colors.
◆Control mode:
AL10RGB: Built-in color screen controller, ILDA input and output, DMX512, automatic, voice control, master-slave mode.
◆ Computer interface: compatible with ILDA standard computer laser show software control. All ILDA signals are converted using electronic switches.
◆Safety configuration: laser single point protection, laser key switch, laser emergency remote control interface, eye bolts.
◆Safety intelligence: A single point caused by failure of the scanning motor or control system will force the light to be turned off. PC control and built-in program mode automatically identify and switch; in the automatic master-slave synchronization, DMX and PC control modes, the light will be automatically turned off when there is no signal.
◆Power supply: 100~250V, 50/60HZ, 100W
◆ Application places: discotheques, dance halls, bars, nightclubs and various large-scale performance venues. It can operate at low temperatures outdoors.
