1) H.264 Encode
2) Double core 32bit DSP XM510 For 720P 960P/HI3518E For 1080P
3) 1/4inch 1.0 megapixel CMOS sensor, color:1.0lux/F1.2, b/w:0.1lux/F1.2
4) With IR-CUT, support day/night switch
5) 1.0 megapixels 25fps(Full real time) For 720P,22fps for 960P,15fps for 1080P
6) Support ONVIF;Support Third-party NVR
7) 24pcs IR Leds,15m ir distance for night vision
8) Multi-screen software and CMS
9) Image processing: auto exposure(AE), auto white balance(AWB), auto gain control(AGC)
10) Support motion detection
11) Support visit by smart phone
|Image Capture||Video Res||1080P (1920×1080)/960P (1280X960)/ 720P HD (1280 x 720 pixels) Optional|
|Use For||Standard and Professional|
|Image Sensor||Image sensor||1/2.7” SC2135 For 1080P ;OH65 For 960P/ 1/4″ OH42 CMOS For 720P|
|Resolution||2.0MP 1080P/1.3MP 960P / 1.0MP 720P|
|Min Illumination||Color: 0.01Lux F1.2, B/W: 0.08 Lux F1.2|
|Size||M12 2.8mm 3.6mm 6mm Optional|
|Interface||Communication Interface||1 RJ45 10M / 100M ethernet port|
|DC||Yes (Not Included )|
|Domain Name||Server||P2P Server/ DDNS server|
|Image Frame Rate||720P 25fps/960P 22fps /1080P 15fps|
|Resolution||1920*1080/1280X960/1280 x 720|
|Bit Rate||32 Kbps ~ 8 Mbps|
|Image settings||Saturation, brightness, contrast adjustable through client software or web browser|
|Video Parameters||Contrast, Brightness, Saturation, Hue|
IR LED 24pcs IR LED with 15M IR Distance
Material High Quality ABS Plastic
Power DC 12V For DC 12V Version / 48V PoE Switch or Injector For 48V PoE Version (NOT INCLUDED )
Q:What’s the default ip address of the camera ?
F: 192.168.1.10 Username : admin Password : null ( empty ) !
Q: Does the camera supports Motion Detect,FTP,Email alarm, RTSP and so on ?
F: Yes ! All the IP Cameras we are selling supports these functions .
1) Please Setup the motion detection in the CMS software .
2) We suggest the Sever-U and FileZilla FTP Server to upload the video or image.
3) For the Email alarm,please use Email server which supports SMTP ( Hotmail ,Yahoo not support SMTP ,try Gmail please ) .
4) ,RTSP URL for VLC media Player :
Example : rtsp://10.6.10.25:554/user=admin&password=&channel=1&stream=0.sdp?real_stream
F: What’re the ports information of the cameras ?
Q : ONVIF 2.0 Port 8899 ;RTSP Port 554 ;HTTP Port 80;Media Port 34567
F:Does the camera support IE ,Chrome ,Firefox and so on ?
Q: Since the plug-in problem ,for website interface IP address URL,ONLY IE supports Multi Language . Chrome,Safari just support Chinese .
For cloud server XMEYE.NET ,it supports multi language
Q:When I finish the steps to add the camera to the CMS list,why it notify “ Can’t find the Device “ even I can see the default ip address 192.168.1.10 in the menu .
F: It is the IP Address conflict ,the default ip address is not in the same network segment as your router.
Please click “Edit Device “ to change the camera’s ip address to make them in the same network segment !
For example ,if your router’s ip address is 192.168.0.1 ,then you need to change the camera’s ip address to 192.168.0.XX .
1 * Bullet Camera
1 * CD With manual included
Note : There are two versions optional,one is DC 12V ,the other 48V PoE Version
For the DC 12V Version,it has two interface ,one is DC Plug ,the other ethernet connector,
which just can work with 12V DC power supply 1A-2A (Not Included )
For the 48V PoE Version ,it just has one ethernet connector which just can work with 48V PoE Switch or Injector.
