· Up to 3K high definition live viewing
· Up to 3K Lite recording & playback
· Advanced H.265 Pro+ Video Compression
· Support TVI/AHD/CVI/CVBS/IPC input. 5 in 1
· Supports iPhone、iPad、Android mobile remote monitoring
· Deep learning based human and vehicle targets classification of Motion Detection 2.0 for all analog channels
· Quick search by object or event type
· Audio via coaxial cable

|
DVR |
||
|
Video & Audio |
Video Compression |
H.264+/H.264/H.265/H.265 Pro+ |
|
Video Input |
8CH Analog HD/Analog + 2CH IP Video (up to 12 channel when IP enhanced mode on) |
|
|
Video Output |
HDMI and VGA Up to 1080P |
|
|
Audio Input |
1-ch RCA,8-ch via coaxial cable |
|
|
Audio Output |
1-ch RCA |
|
|
Supported Camera Types |
Support HD TVI Input: 3K/5MP@20FPS, 4MP, 3MP, 1080p, 720p; |
|
|
Analog HD Playback Resolution |
3K Lite/5MP Lite/4MP Lite@12fps,1080p/720p@15fps |
|
|
IPC Playback Resolution |
Up to 6MP |
|
|
Max Playback Channel |
8-ch |
|
|
Network Protocols |
TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS |
|
|
Total Bandwidth |
96Mbps |
|
|
Remote Connection |
64 |
|
|
Motion Detection 2.0 |
All analog channels support human and vehicle detection to reduce false alarm |
|
|
Hard Drive |
HDD |
1 SATA interface |
|
HDD Capacity |
Up to 10TB capacity |
|
|
External Interface |
Network interface |
1, RJ45 10M/100M self-adaptive Ethernet interface |
|
USB |
USB2.0x2 |
|
|
General |
Operating Power |
DC12V,≤ 12W (without HDD) |
|
Working Temperature |
-14 °F – 131 °F /-10 °C – 55 °C |
|
|
Dimensions(W x H x D) |
260 × 222 × 45 mm (10.2 × 8.7 × 1.8 inch) |
|
|
Weight (without hard disk) |
≤ 1 kg (2.2 lb)(without HDD) |
|
